Hikvision DS-2CD2047G2-L(U) 4MP ColorVu Fixed Mini Bullet Network Camera

Specifications of Hikvision DS-2CD2047G2-L(U) 4MP ColorVu Fixed Mini Bullet Network Camera

• High quality imaging with 2 MP resolution
• Excellent low-light performance
• Efficient H.265+ compression technology
• Water and dust resistant (IP67)
• 24/7 colorful imaging
• 2.8 mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127°
• Main Stream: 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
• Image Enhancement: BLC, HLC, 3D DNR

Camera

• Image Sensor: 1/2.8" Progressive Scan CMOS
• Minimum Lighting:Color: 0.001 Lux @ (F1.0, AGC ON)
• Angle Adjustment:Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
• Lens Type And Field Of View:
• 2.8 mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127°
• 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°
• Depth Of Focus:
• 2.8 mm: 1.7 m to ∞
• 4 mm: 2.1 m to ∞

Video

• Main Stream
• 50Hz: 25fps (1920×1080, 1280×960, 1280×720)
• 60Hz: 30fps (1920×1080, 1280×960, 1280×720)
• Secondary Transmission
• 50Hz: 25fps (640×480, 640×360, 320×240)
• 60Hz: 30fps (640×480, 640×360, 320×240)

Video Compression

• Main stream: H.265+/H.265/H.264+/H.264
• Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate
• 32 Kbps to 8 Mbps

Network

• Simultaneous Live View: Up to 6 channels
• Protocols:
• TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS
• Image
• Day/Night Switch: Day, Night, Auto, Schedule
• Image Enhancement: BLC, HLC, 3D DNR
• Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser

Interface

• Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port

Basic Events

• Motion detection, exception (illegal login)
• General Function: Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via email, pixel counter
• Power Supply: 12 VDC ± 25%, PoE: 802.3af
• Camera Dimension: Ø110 × 100.8 mm (4.3" × 4.0")
• Package Dimensions: 150 × 150 × 141 mm (5.9" × 5.9" × 5.6")
• Camera Weight: approx. 350 g (0.7 lb.)
